Home » Products » Cup Filler Machine » Fully Automatic Cup Filler Machine

Fully Automatic Cup Filler Machine

Fully Automatic Cup Filler Machine
Fully Automatic Cup Filler Machine
Send Inquiry
Product Code : 01
  • Price
  • Rs 9.5 Lakh /Unit INR
Product Description

Technical Specifications

Parameter

Smart Pac - VP

Material of Construction

All contact parts SS 304, main frame –powder coated MS pipe/channels

GMP Model

All contact parts – SS 304, main frame –SS304 covered with SS 304 sheet. Mechanical parts – as per engineering design - SS304/MS/Aluminum/rubber/plastic

Sealing Type

Center seal - other sealing available on request

Sealing Method

Intermittent through pneumatic system

Pouch Width

Maximum 620 mm of roll width Translate to 7” pouch width

Pouch Height

Adjustable – maximum 310 mm.

Packing Range

10 gm to 2000 gm* - limited by pouch size

Vertical Seal Width

10 - 20 mm – typically 15 mm

Vertical Travel of Film

Timer belt controlled by stepper motor drive

Pouch Forming Method

Through SS 304 Collar

Horizontal Seal Width

10-15 mm - typically 10 mm

Power Supply

230 V Ac single phase

Power Consumption

2.0 kw

Gas Flushing system

Available

Half/Full Cut Count

Available

Batch Coding System

Pneumatic ink coding / Hot Foil printing

Heater Control

PID Controller provided front panel

HMI Display

Alfa numeric , 4” LCD back lit display through micro controller based system

HMI Display

2 nos - 1 for weight( volume) setting + 1 for pouch setting

Dispensing Method

By Volumetric Cup


Sensograph Packaging Technology Pvt. Ltd.
