Fully Automatic Weigh Filler Machine

Fully Automatic Weigh Filler Machine
Fully Automatic Weigh Filler Machine
Send Inquiry
Product Code : 01
Price And Quantity
  • Unit of Measure
  • ,
  • Price
  • Rs 1.5 Lakh /Unit INR
  • Price Range
Product Description

Technical Specifications

Parameter

Smart Auto - EP

Material of Construction

All contact parts SS 304, main frame –powder coated MS pipe/channels

GMP Model

All contact parts – SS 304, main frame - SS304 covered with SS 304 sheet. Mechanical parts – as per engineering design - SS304/MS/Aluminum/rubber/plastic

Sealing Type

Center seal - other sealing available on request

Sealing Method

Intermittent through pneumatic system

Pouch Width

Maximum 390 mm of roll width Translate to 7” pouch width

Pouch Height

Adjustable – maximum 310 mm.

Packing Range

10 gm to 2000 gm* - limited by pouch size

Vertical Seal Width

10 - 20 mm – typically 15 mm

Vertical Travel of Film

Metallic roller controlled by stepper motor drive

Pouch forming method

Through SS 304 former

Horizontal seal width

10-15 mm - typically 10 mm

Power Supply

230 V Ac, Single Phase

Power Consumption

1.5 Kw + 300 VA per head

Gas Flushing system

Available

Half/Full cut count

Available

Batch coding system

Pneumatic ink coding / Hot Foil printing

Heater control

PID controller provided on front panel

HMI Display

Alfa numeric , 4” LCD back lit display through micro controller based system

HMI Display

2 nos - 1 for weight setting + 1 for pouch setting

Dispensing Method

By weight this Linear Vibratory
